Nauja Asfalto gamykla POLYGONMACH 320tph Stationary asphalt plant with 270 tons hot asphalt storag

1.1 COLD AGGREGATE FFEDING CHASSIS 5

1.2 Feeding bunkers and dosage conveyor bands 1+1

1.3 Collector and dryer mounted on the feeding conveyor band 1

1.4 STATIONARY CHASSIS 1

1.5 ROTARY DRYER GROUP 1

1.6 Dryer body 1

1.7 Aggregate inlet head 1

1.8 Aggregate outlet head 1

1.9 Burner group (BALTUR) 1SET

1.10 Burner fuel pump 1

1.11 Burner blower fan 1

1.12 Elevator inlet 1

2.1 MIXER CHASSIS GROUP 1

2.2 Asphalt Mixer + Hot Aggregate Elevator 1

2.3 Aggregate weighing scale bunker 1

2.4 Filler Elevator and Weighing scale bunker 1

2.5 Filler Screw Conveyor 1

2.6 Bitumen weighing scale bunker 1

2.7 Mixer bitumen pump 1

2.8 Undersize hot aggregate silo(50T) 1

2.9 Filler stock silo 25 M3 1

2.10 Vibration Screen 1

3 DUST COLLECTING FILTER SET

3.1 Jet-Pulse filter body 1 Set

3.2 Nomex filter bag and cartridges 1 Set

3.3 Dust collector V spiral and bunker 1+1 Set

3.4 Filler silo(25Tons) 1 Set

3.5 Filler Screw Conveyor 1 Set

3.6 Filter absorption fan 1Set

3.7 Dirty gas channel 1 Set

3.8 Chassis group 1 Set

4 BITUMEN STOCK TANK

4.1 40 Ton capacity boiling oil heating isolation bitumen tank 4 SET

4.2 3 way pneumatic jacket valve group 2 SET

4.3 Mixer bitumen feeding pump 1 SET

4.5 Mixer bitumen weighing scale feeding pipe line 1 SET

4.6 Bitumen transfer pump 1 SET

4.7 Double wall bitumen pipe installations 1 SET

4.8 30 Ton capacity boiling oil heating isolation bitumen tank 3 SET

4.9 3 way pneumatic jacket valve group 2 SET

5 FUEL AND THERMAl GENERATOR CHASSIS GROUP

5.1 1.500.000 kcal/h capacity Thermal oil generator 1 SET

5.2 Boiling oil heating boiler 1 SET

5.3 Boiling oil circulation pump 1 SET

5.4 Fuel replenishing pump 1 SET

5.5 Fueling pump 1 SET

5.6 Automation-Control Cabin-Software-Compressor 1 SET
